Hi everybody,

first of all many thanks to the maker of the original version RubenMts :)
I really enjoyed printing and making it work !

Why making a remix?

After printing the original version there where few files to change - already developed by other makers in the community (see comments in the original version)

• mini_gear
• gear_ratchet
• case_ratchet

-> I collected these updated files in my version too.

Secondly I made a more massive coin_holder to have a better force absorption and made it a little thinner for better fitting.

Thirdly, following these additional instructions will make it work for the 4 counter version.

I made a little grinding at the following parts to have a better fitting - grain size(80-120)

• axis
  -> the shaft has to be grinded
• counter_wheel_x3
  -> ca. 0.2 mm at the driver tooth face
• counter_wheel_toothing
  -> ca. 0.2 mm at the driver tooth face
• case_ratchet
  -> bottom, left and right side for better fitting in the case

Always try and error if it already fits or not :)

Finally the assembly part
-> see file assembly_instructions.docx

PS: Added the coin_holder CAD file if you want to change coin slot. Current version is prepared for 5 cent € coin ;)

Have fun and leave feedback :)
