Terminal Blocks – MaxPro Edition

Materials:

  1. Copper terminal blocks and neutral/ground busbar (essential; specifications as shown in the diagram)
  2. Insulated terminal blocks (essential; specifications as shown in the diagram)
  3. Heat‑shrink nuts (optional—no strict requirement for these; can be replaced with electrical tape if preferred)
  4. Screws with square washers (optional—screws already included on copper terminal blocks can also be used)

Printing Conditions:

  1. No supports are required for any of the parts (provided adequate cooling is ensured; we recommend enabling supports during summer months)

Bill of materials

  • Name
    Quantity
    Notes
  • 1
    铜接线端子、零地排
    1
    (必备，规格如图)
  • 2
    绝缘接线端子
    12
    (必备，规格如图)
  • 3
    热熔螺母
    2
    (可不买，无硬性固定要求，可用胶带替换，规格如图)
  • 4
    带方垫螺丝
    16
    (可不买，铜接线端子上自带螺丝也可用，规格如图)

Originality of the Model

The author declares that this work is their personally original model

This model is licensed under the following terms:

Standard Digital File License

This work is licensed under a Standard Digital File License. Digital files have a strict non-commercial, personal use only license.

You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital file or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including remixes of this object). You can not host these files on other digital platforms, web stores or cloud repositories. The objects may not be used in any way whatsoever in which you charge money, collect fees.
