What It Is



A trickle vent is a small, built-in slot or grille, usually located at the top of a window or door frame, that allows a controlled flow of fresh air into a room even when the window is closed and locked. It typically features a sliding or flap mechanism that can be manually opened or closed, though it is designed to remain open most of the time for continuous ventilation.



How It Works



The vent works passively, using the natural pressure difference between the inside and outside of the building, caused by wind and the stack effect (warm air rising inside the building). This allows stale, humid air to escape while fresh, drier air enters, providing a small but consistent airflow—usually around 5–10 litres per second per vent. This background ventilation helps regulate humidity, reduce condensation, and prevent mould growth without the heat loss associated with fully opening a window.



Benefits



Prevents condensation and mould by continuously removing moisture-laden air,
Maintains indoor air quality by allowing pollutants and CO2 to escape.
Energy-efficient because it provides ventilation without significant heat loss.
Discreet and unobtrusive, blending into modern window designs.

Originality of the Model

The author declares that this work is their personally original model

This model is licensed under the following terms:

Standard Digital File License

This work is licensed under a Standard Digital File License. Digital files have a strict non-commercial, personal use only license.

You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital file or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including remixes of this object). You can not host these files on other digital platforms, web stores or cloud repositories. The objects may not be used in any way whatsoever in which you charge money, collect fees.

Models(2)

  • model file image
    Trickle Air Vent.3mfDesigner

    114.49 KB

    2026-07-13

  • model file image
    Trickle Air Vent.stlDesigner

    396.37 KB

    2026-07-13
