Layer Height

0.03 mm (30 microns)

Provides much smoother curves than the standard 0.05 mm.

Bottom Layer Count

6 - 8

Ensures a rock-solid foundation for the build plate.

Exposure Time

2.2 - 2.5s

Standard for most 8K/DLP resins; adjust based on specific resin brand.

Bottom Exposure Time

25 - 30s

Provides strong adhesion without over-curing the base too much.

Transition Layer Count

10

Smooths the transition between bottom and normal layers.

Wait After Lift

0.5s

Allows the resin to stabilize and stop moving before the next shot.

Lift Distance

3 + 4 mm (Two-stage)

Helps safely peel the large surface area of the character's body.

Lift Speed

60 & 180 mm/min

Slow initial lift prevents suction damage to fine details.

Retract Speed

180 & 60 mm/min

Slows down at the end to prevent air bubbles under the model.
