Repurposing an idle 8020 cooling fan into a desktop or handheld portable fan
Print Profile(1)
  • 0.2 mm layer height, 2‑wall walls, 15% infill density

    1-disc

    PETG

    Designer

0

1

6

0

Released 2026-04-20
Details
Files(1)
Makes & Comments (0)

           Build a portable handheld/desktop fan using an idle 8020 fan



           The compatible cooling fan size is 8020,

           Two 18650 batteries can be placed inside the battery compartment to provide a certain runtime (for personal use, a 12V fan with a 2S/18650 configuration is recommended; for 5V fans, a 2P configuration with two 18650s is suggested)

           The charging board slot supports either a 2–3S charging module or a single-cell TP4056 module

           The boat-shaped housing measures 13×8 mm; four M2×15 mm self-tapping screws are required at the bottom, while the top can be secured with M3×25 screws or adhesive



           Low cost and highly practical

Bill of materials

  • Name
    Quantity
    Notes
  • 1
    8020散热风扇
    1
  • 2
    13X8mm船开关
    1
  • 3
    M2*15mm自攻螺丝
    4
  • 4
    m3*25mm螺丝
    2
  • 5
    任意胶水 可选
    1
  • 6
    18650
    2
