Based on the Printacaster, which in turn is based on the Prusacaster.

This remix allows for HSS pickups.

The components are connected using M3 bolts/screws, and heat set inserts of size M3*5*4

You may need to adjust the neck pocket based on your neck, so I've included my step file.

The original has a well detailed guide on assembly.

[Remix Info]
Here's what I've changed from the original:

1. I had to modify the cavities where the guitar pickups go, to accommodate the different configuration. This also needed me to resize the cavities so that the strength wasn't affected, and everything was spaced properly.

2. I had to reshape the geometry for some of the hexes and how the parts fit together here as well, to accommodate the configuration.

3. I changed the positioning of the bridge (where the strings are threaded through) and change it to a cavity. The old style was for a cigar tray style bridge, the changes are for a saddle bridge with a slot to thread the strings through.

4. I also modified the pick plate accordingly. I had to widen the slots to accommodate wider pickups, plus it had to match the modified geometry under it.

5. In addition to all of this, i added some aesthetic inserts for some flair.
