Description
Model Description
The low-power motherboard from Zhixin has already sold out after the enclosure was completed; it’s unclear whether more will be available.
- The enclosure can easily accommodate three strings of 18650 or 21700 cells; when inserting them, ensure proper insulation and secure them with adhesive for a more flexible and convenient setup.
- Directly solder the batteries to the back panel—do not use connectors, as the height is insufficient.
Other Accessories:
Name | Quantity | Description |
| m2*5 round-head self-tapping screws | 4 | to secure the motherboard (if the screw heads are too large, add insulating washers) |
| m2*5 round-head self-tapping screws | 3 | to secure the front circular decorative cover (do not use longer screws, as they may press against the motherboard) |
| m3*12 round-head self-tapping screws | 4 | to secure the front and rear enclosures |
| 16mm 12V self-locking push-button switch (optional) | 1 | a mounting hole is预留 at the rear for installing a switch on the battery; this is optional and can be omitted if not needed. |
| Note: Non-self-tapping screws can also be used, but the initial assembly will be more challenging. Decorative components must be secured with adhesive. | ||
Installation Sequence:
- After installing the forward/reverse button, mount the motherboard onto the front enclosure,
- If installing a rear switch, first install the decorative component on the rear enclosure,
- Secure the front and rear enclosures with screws,
- The installation of other decorative components can be done in any order.
Originality of the Model
The author declares that this work is their personally original model
This model is licensed under the following terms:
This work is licensed under a Standard Digital File License. Digital files have a strict non-commercial, personal use only license.
You shall not share, sub-license, sell, rent, host, transfer, or distribute in any way the digital file or 3D printed versions of this object, nor any other derivative work of this object in its digital or physical format (including remixes of this object). You can not host these files on other digital platforms, web stores or cloud repositories. The objects may not be used in any way whatsoever in which you charge money, collect fees.
