This 90-degree angle bracket is a 3D printed corner plate designed to securely join two wooden pieces at a right angle.
The bracket features two mounting holes, allowing it to be easily screwed into place for a strong and precise square connection. Its simple, flat design makes it practical, reliable, and easy to print.
Key Features
- Perfect 90° angle for accurate alignment
- Two screw holes for secure mounting
- Ideal for wooden structures and frames
- Compact and functional design
- Optimized for 3D printing
- Easy to scale for different sizes and uses
3D Printing Recommendations
- Supports: not required
- Layer height: 0.2 mm
- Infill: 30–40% recommended for strength
- Material: PETG or ABS recommended for higher durability (PLA for light-duty use)
Ideal Applications
- Furniture assembly
- Shelves and frames
- DIY projects
- Workshop and woodworking setups
A simple and effective 90-degree bracket, perfect for clean, square joints in woodworking and DIY applications.
