A feeding device specifically designed for 15mm-thick glass aquariums. The design consists of two main components: a vertical mounting bracket and an oval base. The bracket’s vertical structure securely clamps onto the aquarium’s glass edge, while the base provides stable support. At the center of the base is a standard cylindrical socket that firmly accepts a feeding tube or dispensing tube, allowing it to hang vertically in the water for precise, measured feedings. The bracket sits flush with or slightly below the waterline, ensuring discreet, clean feeding operations.

Design Highlights

• Specialized Clamp for Thick-Walled Aquariums

  The slot design is meticulously engineered to perfectly match the edges of 15mm‑thick glass, offering a secure grip while remaining easy to install—without damaging the aquarium’s surface.

• Concealed Underwater Installation

  The feeder is fully submerged, taking up no space on the aquarium’s exterior and preserving its aesthetic appeal, while also preventing dust and debris from contaminating the water.

• Sturdy, Interlocking Base

  The depth and diameter of the base’s socket have been optimized to ensure a snug fit with standard feeding tubes, effectively preventing wobbling, dislodging, or floating during use.

• Robust Construction, Minimal Footprint

  The two components work seamlessly together, featuring a simple yet sturdy design that is compact in size—leaving ample room for aquarium decor and fish movement.

Technical Specifications

• Compatible Aquariums: Glass tanks with a wall thickness of 15mm
• Compatible Feeding Tubes: Standard‑diameter soft or rigid feeding tubes
• Recommended Materials: Food‑grade PETG or ABS (safe for long‑term immersion in water)
• Installation Location: Along the aquarium’s edge, adjustable to any depth below the water surface
• Printing Tips: It’s recommended to polish the inner walls of the bracket slots to reduce stress and ensure even clamping force; the inner walls of the base’s socket should be smooth and free of imperfections.

Application Scenarios

▸ For planted tanks, crystal shrimp tanks, and other setups requiring precise, hygienic feeding

▸ Precise, point‑specific feeding in fry hatchery isolation tanks

▸ Reducing human interference when keeping fish that are easily startled

▸ Use in conjunction with automatic feeders for extended periods away from home
